Design and Operating Features

• Gantry Linear Motion System

• Siemens 840D CNC

• Motion system 6025 x 2025 x 120 mm

• 6000 watt laser

• Dual circuit water chiller

• Constant beam length axis and optics to suit

• Windows XP operating system

• Ergonomic machine separated, free positioned CNC control cabinet

• 15¨ TFT colour monitor

• 3 MB Program data storage

• Transfer tables (dual palette) Hydraulic lift (integrated drive system)

• Programmable high pressure air / nitrogen gas selection 1.. 25 bar.

• Advanced precitec cutting head (with air cross blast) 7.5¨ & 10¨ lenses

• Pierce detection, cut monitoring & Lens failure detection

• Auto nozzle cleaning and calibration

• Standard fume extraction system

• Parts debris conveyor

• Lantek Nesting system

• In built safety systems (light guards & full enclosure as standard)

• CE Compliance

Uniqueness

• Ease of processing both large and small size formats

• High speed water cooled linear motors

• No repositioning of plate ensure accuracy

• Flying optics and Constant Beam Length axis.

• Simple operator interface and cutting database

• Dual pallets

• Superior accessibility to work areas

• Hand-held pendant for remote access to setup, adjustment and management of waste skeletons

• Tactile height following for non conductive materials

• Fully enclosed, purged beam path
